Tunnel Tractor Battery 537V420Ah
Tunnel Tractor Battery 537V420Ah
Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 537V and energy is 225kWh.
A+ class LiFePO4(Lithium Iron Phosphate) cells, up to 3000cycles(8-10years). The capacity remains higher than 80% after 2000+cycles, even after 3500+cycles(10-12years), the capacity can still be over 70%.
Battery cells packing process is completely in accordance with the standards of EV Battery production, embracing the laser welding techniques to ensure every cell to be soldered completely, avoiding insufficient or poor soldering.
Data Sheet
-
Safe & Endurable
Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.
-
Smart BMS
The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.
-
10 Years Design Life
A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.
-
Reliable
Longer lifespan Laser Welding Rigid tests before shipment.
-
Adaptable
Self-heating function, consistent and efficient at -20 to 50 degrees.
-
Intelligent Monitoring
Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.
-
LiFePO4
A+ Tier Cells
-
537V
Voltage
-
225kWh
Energy
-
≥3500
Battery Cycles
-
5years
Warranty
| 537V420Ah- EV Battery- Tractor Trailer | |||
| SPECIFICATIONS | |||
| Rated Capacity | 420Ah | ||
| Rated Energy | 225kWh | ||
| Nominal Voltage | 537V | ||
| Dimension | 2884*1480*906mm | ||
| Weight | approx. 3.5T | ||
| Color | Gray | ||
| High Voltage Cable Length | 6.5m | ||
| Low Voltage Cable Length | 6.5m | ||
| Display Screen | 8mm | ||
| Working Voltage | 420-613.2V | ||
| Max. continuous charge Current | 336A | ||
| Max. continuous discharge current | 420A | ||
| 10S Pulse Current | 630A | ||
| Protection Level | IP65 | ||
| Charging Port | 2pcs(R-1pcs, L-1pcs) | ||
| Working Temperature | Charge: 0～55℃ | ||
| Discharge: -20～60℃ | |||
| Storage Temperature | 0~35℃ | ||
| State of Charge(SOC) before Shipment | 60%~70% | ||
| Life Cycles | ≥2000 @25℃ | ||
| BATTERY MANAGEMENT SYSTEM(BMS) PARAMETERS | |||
| Contexture | 1BMU(Primary)+8CSC(Secondary) | ||
| BMU Working Voltage | 24V | ||
| BMU Power Consumption | <100mA | ||
| BMU Total Voltage Collecting Range | 0~1000V | ||
| BMU Total Voltage Collecting Precision | 5V | ||
| BMU Total Current Collecting Range | ±1000A | ||
| BMU Total Current Collecting Precision | 1% | ||
| BMU SOC Precision | 5% | ||
| BMU Protection | Battery Protection: Charge/Discharge/Temperature/Current/Voltage | ||
| Electrical Protection: Communication/Open Circuit/Short Circuit | |||
| High voltage safety: insulation/contactor sintering, etc. | |||
| CSC Single Unit Voltage Detecting Range | 0~5V | ||
| CSC Single Unit Voltage Detecting Precision | ±5mV | ||
| CSC Temperature Detecting Range | -40~125℃ | ||
| CSC Temperature Detecting Precision | ±5℃ | ||
| PROTECTION PARAMETERS | |||
| High Temperature Alarm | >60℃ | Alarm level3: extremely high temperature | serious!cut off the charge & discharge |
| >55℃ | Alarm level2: very high temperature | general alarm | |
| >50℃ | Alarm level1:high temperature | general alarm | |
| Low Temperature Alarm | <-20℃ | Alarm level3: extremely low temperature | serious! stop charging, cut off the charge & discharge |
| <-15℃ | Alarm level2: very low temperature | general alarm | |
| <-10℃ | Alarm level1: low temperature | general alarm | |
| Temperature Difference Alarm | >20℃ | Alarm level3:extremely big difference | serious! cut off the charge & discharge |
| >15℃ | Alarm level2:very big difference | general alarm | |
| >10℃ | Alarm level1: big difference | general alarm | |
| Over-voltage Alarm | Single Cell>3.75V | Alarm level3: extremely high voltage | serious! cut off the charge & discharge |
| Single Cell>3.70V | Alarm level2: very high voltage | general alarm | |
| Single Cell>3.66V | Alarm level1: high voltage | general alarm | |
| Low Voltage Alarm | Single Cell<2.70V | Alarm level3:extremely low voltage | serious! cut off the charge & discharge |
| Single Cell<2.90V | Alarm level2: very low voltage | general alarm | |
| Single Cell<3.00V | Alarm level1: low voltage | general alarm,Recharge is required! | |
| Total High Voltage Alarm | Total Voltage>630V | Alarm level3: extremely high voltage | serious! cut off the charge & discharge |
| Total Voltage>621.6V | Alarm level2: very high voltage | general alarm, stop charging. | |
| Total Voltage>614.88V | Alarm level1:high voltage | general alarm | |
| Total Low Voltage Alarm | Total Voltage<453.6V | Alarm level3:extremely low voltage | serious! cut off the charge & discharge |
| Total Voltage<487.2V | Alarm level2: very low voltage | general alarm | |
| Total Voltage<504V | Alarm level1: low voltage | general alarm | |
| Insulation Alarm | Insulation Resistance<64KΩ | Alarm level3:extrememly weak insulation | serious! cut off the charge & discharge |
| Insulation Resistance<321KΩ | Alarm level1: weak insulation | general alarm | |
| Imbalance Alarm | Voltage Difference>1V | Alarm level3: extreme imbalance | serious! cut off the charge & discharge |
| Voltage Difference>0.7V | Alarm level2: big imbalance | general alarm | |
| Voltage Difference>0.6V | Alarm level1:imblance | general alarm | |
| Low SOC Alarm | SOC Value<10% | Alarm level3:extremely low SOC | serious! Cut off the discharge |
| SOC Value<20% | Alarm level2: very low SOC | general alarm,Recharge is required! | |
| SOC Value<30% | Alarm level1:low SOC | general alarm | |
| Big Discharge Current Alarm | >504A | Alarm level3: extremely big | serious! cut off the charge & discharge |
| >483A | Alarm level2: too big | general alarm, 5seconds | |
| >462A | Alarm level1:big | general alarm, 5seconds | |
| Charging Current | >504A | Alarm level3: extremely big | serious! cut off the charge & discharge |
| >483A | Alarm level2: too big | general alarm, 5seconds | |
| >462A | Alarm level1:big | general alarm, 5seconds | |
| BMS Error | Alarm level3: internal network communication error | serious! cut off the charge & discharge | |
| Communication Error | Alarm level3:Charging communication error | serious! cut off the charge & discharge | |
| Discharge Relay Error | Alarm level3 | serious! cut off the charge & discharge | |
| Charge Relay Error | Alarm level3 | serious! cut off the charge & discharge | |
