All-in-one Residential ESS 5kWh

All-in-one series comes with two models, 2.56kWh(FA3000A) and 5.12kWh(FA5000A), both models have been integrated with inverter that is best suited for offgrid solar system. Plug and use type. To be designed for homes with demand for small and medium power storage.

To be designed for homes with demand for small and medium power storage.

All-in-one Residential ESS 5kWh
All-in-one Residential ESS 5kWh
All-in-one Residential ESS 5kWh
All-in-one Residential ESS 5kWh
All-in-one Residential ESS 5kWh
>
<
Product Features
  • Safe & Endurable

    BMS & Inverter have been proven to be the reliable, durable based on over 20years technological hands-on experience.

  • Effortless Connection

    Inverter integrated without hassle of extra wire connection to between the battery and inverter.Plug and use.

  • For Small Power Storage

    2.56kWh cater for homes with small or medium-power loads that consume power less than 5kWh at night.

  • Built-in Inverter

    Built in a premium sine wave inverter, combined with a lithium battery module, to provide excellent performance and is suitable for charging from solar panels and powering electrical load applications.

  • Easy to Set up

    Raja all-in-one series household energy storage system is designed with PV interface for off-grid solar systems. Thanks to the compact integrated design, it is very convenient for wall-mounted installation, plug and play.

  • Smart BMS

    Powerful intelligent BMS, anti-overheating, over-charging, over-discharge and other multiple protection design, continue to ensure the stable operation of the battery, improve the battery performance, while extending the battery life.

Special Features
  • 8P8S

    LiFePO4 cells

  • 5kVA

    Inverter

  • 5.12kWh

    Battery energy

  • ≥3000

    Cycle life

  • 3years

    Warranty

Specifications
Technical specification FA5000A
Inverter characteristic
Inverter type Off-grid
AC rated power/Peak power 5.5kW/11kW
Vac input/output voltage 230V±5%
PV MPPT range 120~450V
PV Maximum input current 20A
Maximum charging current 50A
Battery Chracteristic
Nominal voltage 51.2V
Rated capacity 100Ah(0.5/25℃)
Rated energy 5.12kWh (0.5/25℃)
Display LCD/APP

Size

590×800×240mm
Weight 70kg

Protection level

IP40
Working temperature Charge: 0~55℃
Discharge: -20~60℃
Storage temperature 10~35℃
Inverter Characteristic
UN38.3/MSDS/ICE 62619/ICE61000-6-1/CE61000-6-3/ROHS/WEEE
Product Details

Project Cases

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

>
<
Solutions

Residential ESS

Thanks to its combination with photovoltaic systems, YAJUN House ESS makes green energy available 24/7, providing a clean electricity solution for your own solar-powered home. If you are looking for a home solution that is safe, reliable and easy to install, the YAJUN is ideal for homeowners using solar power. Enjoy your unparalleled green energy experience, optimal solar energy use, reduced electricity bills and much more.

Learn More >

C&I ESS

YAJUN provides commercial and industrial energy solutions for EPCs, developers, and owner-operators to utilize the roof resources. With unrivalled technical expertise and optimized design, GoodWe can comprehensively drive new revenue streams and project value for our users with high-current PV module compatibility.

Learn More >

Balcony Solar System

The balcony solar system is specially designed for small Spaces such as balconies or terraces micro-photovoltaic power stations. Combined with an intelligent management platform, the solution can generate clean, renewable energy to power a home or apartment. it is an ideal choice for owners who do not want to occupy outdoor space or lack outdoor installation space.

Learn More >

PV power station integrated solution

PV power station integrated solution integrates solar, storage, and charging station system into a single solution, which not only meets the challenges related to limited land and electrical capacity resources but also achieves a balance between local energy production and electrical load through energy storage and optimal configuration.

Learn More >
>
<
