Hybrid Inverter Single Phase 5kW

5kW Single-phase Hybird Inverter

RAJA single-phase hybrid inverter supports simultaneous input of photovoltaic, battery, diesel generator, power grid, and load for self-use, peak adjustment and valley compensation, and backup power supply.

It supports parallel connection of multiple machines and is suitable for various applications of energy storage in villas, communication base stations, farms and residential homes.

Hybrid Inverter Single Phase 5kW
Hybrid Inverter Single Phase 5kW
Hybrid Inverter Single Phase 5kW
>
<
Product Features
  • Switching

    Automatic battery switching.

  • Options

    Input power source priority can be set by users.

  • Multi-Source

    Support Diesel Generator Input Source.

  • Compatibility

    Compatible with Lead-acid and Lithium-ion Batteries.

  • Expansion

    Parallel available, intelligent BMS management.

  • Protection

    Battery Reverse Connection protection, anti-power control function.

Special Features
  • Luxury Villa

  • Communication Base Station

  • Nomadic Farm

  • Residential Electricity

Specifications
Single Phase Hybrid Inverter
PV Input Parameters
Max Power(kW) 7
Max DC Voltage(V) 550
MPPT Voltage Range(V) 125~500
Single MPPT Max Input Current(A) 14
MPPT NOS/ Series & Parallel 44958
AC Output Parameters
Rated Output Power(kVA) 5
Max Output Current(A) 21.7
Grid Voltage Range(V) 230/176~270
Grid Frequency(Hz) 50 /60
Power Factor 0.8advance ~0.8lagging
THDi <3%
Grid Connection Type L+N+PE
Battery Parameters
Voltage Range(V) 40~58
Max Charging Voltage(V) 58
Max Charge/Discharge Current(A) 95/104.2
Battery Type Lithium / Lead Acid
Communication Interface CAN/RS485
EPS Output Parameters
Rated Power(kVA) 5
Rated Output Voltage(V) 230
Rated Output Current(A) 21.7
Rated Output Power(Hz) 50 /60
Auto Switch Time(ms) <20
THDu <2%
Overload Ability 110%, 30S/120%, 10S/150%, 0.02S
General Parameters
Charge/Discharge Efficiency 0.95
Max Efficiency 0.976
Efficiency for EU 0.97
MPPT Efficiency 0.999
Protection Level IP65
Noise(dB) <35
Environmental Temperature Range - 25℃~ 60℃
Cooling Method natural cooling
Environmental Humidity Range 0 ~95% (no consendation)
Altitude 2000m (no power descrease)
Dimension W*D*H(mm) 550*200*515
Weight(kg) 25
Static Power Consumption(W) <3
Display & Communication
Display LCD
 RS485/Wifi/4G/ CAN/DRM Optional
Compliance
Safety IEC/EN62109-1/-2, IEC/EN62477-1
EMC IEC/EN 61000-6-1, IEC/EN 61000-6-3
Ongrid South Africa NRS097-2-1:2017, UK G98,G99
Project Cases

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

>
<
Solutions

Residential ESS

Thanks to its combination with photovoltaic systems, YAJUN House ESS makes green energy available 24/7, providing a clean electricity solution for your own solar-powered home. If you are looking for a home solution that is safe, reliable and easy to install, the YAJUN is ideal for homeowners using solar power. Enjoy your unparalleled green energy experience, optimal solar energy use, reduced electricity bills and much more.

Learn More >

C&I ESS

YAJUN provides commercial and industrial energy solutions for EPCs, developers, and owner-operators to utilize the roof resources. With unrivalled technical expertise and optimized design, GoodWe can comprehensively drive new revenue streams and project value for our users with high-current PV module compatibility.

Learn More >

Balcony Solar System

The balcony solar system is specially designed for small Spaces such as balconies or terraces micro-photovoltaic power stations. Combined with an intelligent management platform, the solution can generate clean, renewable energy to power a home or apartment. it is an ideal choice for owners who do not want to occupy outdoor space or lack outdoor installation space.

Learn More >

PV power station integrated solution

PV power station integrated solution integrates solar, storage, and charging station system into a single solution, which not only meets the challenges related to limited land and electrical capacity resources but also achieves a balance between local energy production and electrical load through energy storage and optimal configuration.

Learn More >
>
<
